Model No.: Customizable
Brand: Yikang
Out-of-warranty Service: Video Technical Support, Online Support, Spare Parts
Video Factory Inspection: Provided
Mechanical Test Report: Provided
Status: New
Degree Of Automation: Automatic
Power Type: Electric
Place Of Origin: China
Warranty Period: 1 Year
Place of Origin: China
When choosing a thermoforming MAP machine, consider factors such as:
- Production volume requirements
- Type of products being packaged
- Desired package size and configuration
- tmosphere mixture needed
- Available floor space
- Budget constraints
These machines can be highly automated and may include additional features like in-line printing, coding, or inspection systems. Proper maintenance and operator training are crucial for optimal performance and safety.
Main Technical Parameters
| Name | DRZ-420 Technical Parameter | DRZ-520 Technical Parameter |
| Upper film width | 393mm | 493mm |
| Lower film width | 422mm | 522mm |
| Vacuum | -0.1Mpa | -0.1Mpa |
| Compressed air | ≧0.6MPa | ≧0.6MPa |
| Cooling water | ≧0.15MPa | ≧0.15MPa |
| Power Supply | 380V/50HZ (Adapted voltage) | 380V/50HZ (Adapted voltage) |
| Average power | Appr. 7.8KW | Appr. 8.8KW |
| Total weight | appr. 2000kg | appr. 2500kg |
| Overall Dimensions | appr. 6200*900*1850mm | appr. 7900*1000*1850mm |
Product Categories : Thermoforming Packaging Machine > Thermoforming Vacuum Packaging Machine
